Price Of Cleaning And Suction Trucks
A drain valve is installed at the bottom of the tank to facilitate the cleaning of tank waste and effectively protect the high-pressure system. The tank is lifted by hydraulic pressure, and the back cover is opened by hydraulic pressure. A high-level alarm protection device can be installed. The total volume is 10 cubic meters (can freely allocate the volume of clean water and sewage).
Product features:
The tank body and metal accessories of the entire vehicle have been sprayed with polymer anti-corrosion primer and metal topcoat, which have strong adhesion, good corrosion resistance, uniform paint film, bright and long-lasting color, improved aesthetics, and can withstand adverse environments such as humidity, dust, salt spray, etc. Long term use will not cause problems such as cracking, peeling, fading, etc., not only improving the aesthetics of the product, but also effectively preventing rust.
Suction part:
The specialized part of the functional sewage suction truck consists of a power take-off, transmission shaft, vacuum sewage pump, pressure tank body, hydraulic part, pipe network system, vacuum pressure gauge, sight window, hand washing device, etc. The vehicle is equipped with a high-power vacuum sewage pump and high-quality hydraulic system. The tank head is formed by one-time pressure casting, the tank body can be opened backwards, and the double top is self dumping. The dirt inside the tank can be directly dumped through the back cover, which has the characteristics of high vacuum degree (greater than the suction force of the suction truck), large tonnage, high efficiency, and wider application.
Working principle:
The vehicle is started, the power take-off is attached, and the suction pump is driven. The suction pump operates to extract air from the sewage tank. As the suction hose is always submerged in the liquid surface, the air in the sewage tank becomes thinner and thinner due to the lack of replenishment. As a result, the pressure inside the tank is lower than atmospheric pressure, and the sewage enters the tank through the suction hose under atmospheric pressure.
High pressure cleaning section:
The function uses the strong pressure generated by high-pressure water flow to flush open blocked pipelines. The main components are the tank body, high-pressure pump, hydraulic system, etc. High pressure cleaning vehicles are mainly used to clean sediments and dredge dead corners of urban sewers and pipelines. They can also be used to clean industrial drainage pipelines, walls, etc., and to clean roads and square floors.
Working principle: When the vehicle is started, a sandwich power take-off is attached to drive the high-pressure pump. The water is pressurized to hundreds of atmospheres or more through a high-pressure water generating device, and then converted into high-speed micro jet water through a small aperture spraying device. This type of water jet has tremendous impact energy and can complete different types of tasks. The technology of using highly concentrated water jets to complete various pipeline dredging and dredging operations is called "high-pressure pipeline dredging".
【Technical parameters of the entire vehicle】 | |||
Product trademark | Xiangnongda brand | Announcement Batch | 345 (Extended) |
Product Name | Sewage suction truck | Product model | SGW5181GXWF |
Total mass (Kg) | 18000 | Tank volume (m3) | 12 |
Rated load capacity (Kg) | 9220,9155 | Dimensions (mm) | 8700,8500,8400,8200×2500×3600,3450 |
Curb weight (Kg) | 8650 | Cargo compartment size (mm) | ×× |
Rated passenger capacity (person) | Total mass of quasi trailer (Kg) | ||
Cab capacity (persons) | 2,3 | Maximum load capacity of saddle (Kg) | |
Approach Angle/Departure Angle (degrees) | 17/10,17/11 | Front suspension/rear suspension (mm) | 1430/2570,1430/2270 |
Axle load (Kg) | 6500/11500 | Maximum speed (Km/h) | 89 |
remarks | The specialized device for this vehicle consists of a tank and a pump, which are used for sewage discharge and dredging The chassis comes with an optional driver's cab, and the vehicle can also be equipped with a rear structure without a winch This car only has a wheelbase of 4500mm and 4700mm Effective capacity of the tank: 12 cubic meters, transport medium: liquid waste, density: 800 kilograms per cubic meter Corresponding length/wheelbase/straight section length of tank body x diameter: 8700/4700/5000 x 1800 (with winch installed), 8500/4500/4600 x 1900 (with winch installed), 8400/4700/5000 x 1800 (without winch installed); 8200/4500/4600X1900 (without winch installed) The side and rear protective devices are welded to the frame and made of Q235 material. The height dimension of the rear protective section is 120mm, the width dimension is 50mm, and the lower edge is 450mm above the ground ABS manufacturer and model: 3631010-C2000/Dongke Knorr Commercial Vehicle Braking System (Shiyan) Co., Ltd., ABS 8/Dongke Knorr Commercial Vehicle Braking System (Shiyan) Co., Ltd., 4460046450/WABCO Automotive Control System (China) Co., Ltd Optional tank appearance, suction port, and pipeline location. Install left and right fuel tank positions along with the chassis | ||
【Chassis Technical Parameters】 | |||
Chassis Model | DFH1180EX8 | Chassis name | Truck chassis |
Trademark name | Dongfeng brand | manufacturing enterprise | Dongfeng Commercial Vehicle Co., Ltd |
Number of axes | 2 | Number of tires | 6 |
Wheelbase (mm) | 3800,3950,4200,4500,4700,5000,5300,5800,5600,5100 | ||
Tire specifications | 10.00R20 18PR,275/80R22.5 18PR | ||
Number of steel plate springs | 7/9+6,8/10+8,8/9+6,11/10+8,3/10+8 | Front wheel base (mm) | 1876,1896,1920,1950,1914,1934,1980,2000,1815,1860 |
Fuel type | diesel oil | Rear wheel base (mm) | 1820,1860,1800,1840 |
Emission standards | GB17691-2018 National VI | ||
Engine model | Engine manufacturing enterprises | Emissions（ml） | Power (Kw) |
D4.5NS6B190 D6.7NS6B230 B6.2NS6B210 D4.0NS6B185 DDi50E220-60 B6.2NS6B230 DDi50E190-60 D4.0NS6B195 D6.7NS6B260 D4.5NS6B220 DDi47E210-60 | Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Commercial Vehicle Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Commercial Vehicle Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Commercial Vehicle Co., Ltd | 4500 6700 6200 4000 5000 6200 5000 4000 6700 4500 4750 | 140 169 154 136 162 169 147 143 191 162 154 |
The price of cleaning and suction trucks is based on your requirements. We are the source manufacturer and support customization. We will help you select a suitable vehicle based on your specific needs!
