Diesel Suction truck
Diesel suction trucks are becoming increasingly popular due to their low
fuel consumption and low carbon dioxide emissions.
The main advantages of diesel suction trucks include low price, efficient discharge,
strong suction, and good durability.
【Technical parameters of the entire vehicle】 | |||
Product trademark | Xiangnongda brand | Announcement batch | 347 (Extended) |
Product Name | Product model | SGW5182GXWF | |
Total mass (Kg) | 18000 | Tank volume (m3) | 11.6 |
Rated load capacity (Kg) | 10020,9955 | External dimensions (mm) | 7350,7900×2500×3400 |
Curb weight (Kg) | 7850 | Cargo size (mm) | ×× |
Rated passenger capacity (person) | Total mass of quasi trailer (Kg) | ||
Cab capacity (persons) | 2,3 | Maximum load capacity of saddle (Kg) | |
Approach Angle/Departure Angle (degrees) | 19/12 | Front/rear suspension (mm) | 1260/2140 |
Axle load (Kg) | 6500/11500 | Maximum speed (km/h) | 105 |
remarks | This vehicle is used for suction removal of liquid pollutants, and the professional equipment mainly includes tanks, vacuum pumps, etc. The effective volume of the tank is 11.6 cubic meters, and the transport medium is liquid pollutants with a density of 900 kilograms/cubic meter. The corresponding relationship between the vehicle length (mm)/wheelbase (mm)/tank external dimensions (straight section length x diameter) (mm) is 7350/3950/4400 × 18007900/4500/4600 × 1800. The vehicle only uses a wheelbase mm of 39504500. ABS system manufacturer/model: Jiaozuo Borek Control Technology Co., Ltd./JABS. Protection: Q235 is used for both side and rear protective materials, and the connection method with the vehicle is welding. Rear protection: the height above the ground is 450mm, and the section is 120mmX50mm. Optional tank appearance, with optional installation positions for fuel tank, battery, urea tank, and air storage cylinder on both sides along with the chassis. Optional rear drain outlet size | ||
【Chassis Technical Parameters】 | |||
Chassis Model | EQ1185LJ9CDE | Chassis name | Truck chassis |
Trademark name | Dongfeng brand | manufacturing enterprise | Dongfeng Motor Corporation Limited |
Number of axes | 2 | Number of tires | 6 |
Wheelbase (mm) | 3600,3950,4500,4700,5000,5300,5600 | ||
Tire specifications | 295/80R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR | ||
Number of steel plate springs | 8/10+7,8/- | Front wheel base (mm) | 1862,1933,1949 |
Fuel type | diesel oil | Rear wheel base (mm) | 1806,1865 |
Emission standards | GB17691-2018 National VI | ||
Engine model | Engine manufacturing enterprises | Emissions（ml） | Power (Kw) |
CY4SK761 YCS04200-68 D4.5NS6B220 YCY30165-60 B6.2NS6B210 B6.2NS6B230 D4.0NS6B195 YCY30170-60 | Dongfeng Chaoyang Chaochai Power Co., Ltd Guangxi Yuchai Machinery Co., Ltd Dongfeng Cummins Engine Co., Ltd Guangxi Yuchai Machinery Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Dongfeng Cummins Engine Co., Ltd Guangxi Yuchai Machinery Co., Ltd | 4087 4156 4500 2970 6200 6200 4000 2970 | 145 147 162 121 154 169 143 125 |
